Exposing Your Agent to the Internet

Why You Need a Public URL

SignalWire’s cloud needs to reach your agent via HTTP:

Diagram showing that SignalWire's cloud cannot reach your agent running on localhost. — The Problem

Diagram showing ngrok creating a public tunnel from SignalWire's cloud to your local agent. — The Solution: ngrok

Installing ngrok

macOS (Homebrew)

$ brew install ngrok

Linux

$ ## Download
$ curl -s https://ngrok-agent.s3.amazonaws.com/ngrok.asc | \
>   sudo tee /etc/apt/trusted.gpg.d/ngrok.asc >/dev/null && \
>   echo "deb https://ngrok-agent.s3.amazonaws.com buster main" | \
>   sudo tee /etc/apt/sources.list.d/ngrok.list
$
$ ## Install
$ sudo apt update && sudo apt install ngrok

Windows

1 ## Using Chocolatey
2 choco install ngrok
3
4 ## Or download from https://ngrok.com/download

Direct Download

Visit ngrok.com/download and download for your platform.

Create an ngrok Account (Free)

Go to ngrok.com and sign up
Get your auth token from the dashboard
Configure ngrok with your token:

$ ngrok config add-authtoken YOUR_AUTH_TOKEN_HERE

This enables:

Longer session times
Custom subdomains (paid)
Multiple tunnels

Basic Usage

Start your agent in one terminal:

$ ## Terminal 1 (use the command for your language)
$ python my_agent.py       # Python
$ npx tsx my_agent.ts      # TypeScript
$ go run my_agent.go       # Go
$ ruby my_agent.rb         # Ruby
$ java MyAgent             # Java
$ perl my_agent.pl         # Perl
$ ./my_agent               # C++ (compiled)
$ php my_agent.php         # PHP

Start ngrok in another terminal:

$ ## Terminal 2
$ ngrok http 3000

You’ll see output like:

ngrok                                                           (Ctrl+C to quit)
Session Status                online
Account                       your-email@example.com (Plan: Free)
Version                       3.x.x
Region                        United States (us)
Latency                       45ms
Web Interface                 http://127.0.0.1:4040
Forwarding                    https://abc123def456.ngrok-free.app -> http://localhost:3000
Connections                   ttl     opn     rt1     rt5     p50     p90
                              0       0       0.00    0.00    0.00    0.00

Your public URL is: https://abc123def456.ngrok-free.app

Test the Tunnel

$ ## Test locally (use credentials from agent startup output or env vars)
$ curl -u "$SWML_BASIC_AUTH_USER:$SWML_BASIC_AUTH_PASSWORD" http://localhost:3000/
$
$ ## Test through ngrok (use YOUR URL from ngrok output)
$ curl -u "$SWML_BASIC_AUTH_USER:$SWML_BASIC_AUTH_PASSWORD" https://abc123def456.ngrok-free.app/

Both should return the same SWML document.

ngrok Web Interface

ngrok provides a web interface at http://127.0.0.1:4040 showing:

All requests coming through the tunnel
Request/response headers and bodies
Timing information
Ability to replay requests

This is invaluable for debugging SignalWire webhook calls!

Static Domains (Recommended)

Free ngrok gives you random URLs that change each restart. For easier development, use a static domain:

Free Static Domain (ngrok account required)

Go to ngrok Dashboard -> Domains
Create a free static domain (e.g., your-name.ngrok-free.app)
Use it:

$ ngrok http --url=https://your-name.ngrok-free.app 3000

Now your URL stays the same across restarts!

Understanding Basic Authentication

The SDK automatically secures your agent with HTTP Basic Authentication. Every time you start your agent, you’ll see:

Agent 'my-agent' is available at:
URL: http://localhost:3000
Basic Auth: signalwire:7vVZ8iMTOWL0Y7-BG6xaN3qhjmcm4Sf59nORNdlF9bs (source: provided)

The password changes on every restart unless you set environment variables.

Setting Persistent Credentials

For development, set these environment variables to use the same credentials across restarts:

$ ## In your .env file or shell
$ export SWML_BASIC_AUTH_USER=signalwire
$ export SWML_BASIC_AUTH_PASSWORD=your-secure-password-here

Then start your agent:

$ python my_agent.py

Now it will show:

Basic Auth: signalwire:your-secure-password-here (source: environment)

Why this matters:

SignalWire needs these credentials to call your agent
Random passwords mean reconfiguring SignalWire on every restart
Set environment variables once for consistent development

Configure Your Agent for ngrok

Set the SWML_PROXY_URL_BASE environment variable so your agent generates correct webhook URLs:

$ ## In your .env file
$ SWML_PROXY_URL_BASE=https://your-name.ngrok-free.app
$ SWML_BASIC_AUTH_USER=signalwire
$ SWML_BASIC_AUTH_PASSWORD=your-secure-password-here

Or set them when running:

$ SWML_PROXY_URL_BASE=https://your-name.ngrok-free.app \
> SWML_BASIC_AUTH_USER=signalwire \
> SWML_BASIC_AUTH_PASSWORD=your-secure-password-here \
> python my_agent.py

This ensures:

SWAIG function webhook URLs point to your public ngrok URL, not localhost
Authentication credentials remain consistent across restarts

Complete Development Setup

Here’s the full workflow:

$ ## Terminal 1: Start ngrok with static domain
$ ngrok http --url=https://your-name.ngrok-free.app 3000
$
$ ## Terminal 2: Start agent with environment variables
$ export SWML_PROXY_URL_BASE=https://your-name.ngrok-free.app
$ export SWML_BASIC_AUTH_USER=signalwire
$ export SWML_BASIC_AUTH_PASSWORD=your-secure-password-here
$ python my_agent.py
$
$ ## Terminal 3: Test (use the credentials from Terminal 2)
$ curl -u signalwire:your-secure-password-here https://your-name.ngrok-free.app/
$ curl -u signalwire:your-secure-password-here https://your-name.ngrok-free.app/debug

Using a Script

Create start-dev.sh:

$ #!/bin/bash
$ ## start-dev.sh - Start development environment
$
$ NGROK_DOMAIN="your-name.ngrok-free.app"
$ AUTH_USER="signalwire"
$ AUTH_PASS="your-secure-password-here"
$
$ echo "Starting development environment..."
$ echo "Public URL: https://${NGROK_DOMAIN}"
$ echo "Basic Auth: ${AUTH_USER}:${AUTH_PASS}"
$ echo ""
$
$ ## Start ngrok in background
$ ngrok http --url=https://${NGROK_DOMAIN} 3000 &
$ NGROK_PID=$!
$
$ ## Wait for ngrok to start
$ sleep 2
$
$ ## Start agent with environment variables
$ export SWML_PROXY_URL_BASE="https://${NGROK_DOMAIN}"
$ export SWML_BASIC_AUTH_USER="${AUTH_USER}"
$ export SWML_BASIC_AUTH_PASSWORD="${AUTH_PASS}"
$ python my_agent.py
$
$ ## Cleanup on exit
$ trap "kill $NGROK_PID 2>/dev/null" EXIT

Make it executable:

$ chmod +x start-dev.sh
$ ./start-dev.sh

Alternative Tunneling Solutions

Cloudflare Tunnel (Free)

$ ## Install cloudflared
$ brew install cloudflared  # macOS
$
$ ## Quick tunnel (no account needed)
$ cloudflared tunnel --url http://localhost:3000

$ ## Install
$ npm install -g localtunnel
$
$ ## Run
$ lt --port 3000

tailscale Funnel (Requires Tailscale)

$ ## If you use Tailscale
$ tailscale funnel 3000

Production Alternatives

For production, don’t use ngrok. Instead:

Option	Description
Cloud VM	Deploy to AWS, GCP, Azure, DigitalOcean
Serverless	AWS Lambda, Google Cloud Functions, Azure Functions
Container	Docker on Kubernetes, ECS, Cloud Run
VPS	Any server with a public IP

See the Deployment chapter for production deployment guides.

Troubleshooting

ngrok shows “ERR_NGROK_108”

Your auth token is invalid or expired. Get a new one from the ngrok dashboard:

$ ngrok config add-authtoken YOUR_NEW_TOKEN

Connection refused

Your agent isn’t running or is on a different port:

$ ## Check agent is running
$ curl http://localhost:3000/
$
$ ## If using different port
$ ngrok http 8080

Webhook URLs still show localhost

Set SWML_PROXY_URL_BASE:

$ export SWML_PROXY_URL_BASE=https://your-domain.ngrok-free.app
$ python my_agent.py

ngrok tunnel expires

Free ngrok tunnels expire after a few hours. Solutions:

Restart ngrok
Use a static domain (stays same after restart)
Upgrade to paid ngrok plan
Use an alternative like Cloudflare Tunnel

What’s Next?

Your agent is now accessible at a public URL. You’re ready to connect it to SignalWire!

You’ve Completed Phase 1!

Installed the SDK
Created your first agent
Set up development environment
Exposed agent via ngrok

Your agent is ready at: https://your-domain.ngrok-free.app

Next Chapter: Architecture - Deep dive into SWML, SWAIG, and agent architecture

Or jump to: SignalWire Integration - Connect your agent to phone numbers
