Docker & Kubernetes | SignalWire

Dockerfile

Each language has a different Dockerfile. Choose the one matching your SDK language.

Python

TypeScript

1 FROM python:3.11-slim
2
3 WORKDIR /app
4
5 ## Install dependencies
6 COPY requirements.txt .
7 RUN pip install --no-cache-dir -r requirements.txt
8
9 ## Copy application
10 COPY . .
11
12 ## Create non-root user
13 RUN useradd -m appuser && chown -R appuser:appuser /app
14 USER appuser
15
16 ## Expose port
17 EXPOSE 3000
18
19 ## Run with uvicorn
20 CMD ["uvicorn", "app:app", "--host", "0.0.0.0", "--port", "3000", "--workers", "4"]

Application entry point (Python)

1 ## app.py
2 from signalwire import AgentBase
3
4 class MyAgent(AgentBase):
5     def __init__(self):
6         super().__init__(name="my-agent")
7         self.add_language("English", "en-US", "rime.spore")
8         self.prompt_add_section("Role", "You are a helpful assistant.")
9
10 agent = MyAgent()
11 app = agent._app

Building and running

$ ## Build image
$ docker build -t signalwire-agent .
$
$ ## Run container
$ docker run -d \
>   -p 3000:3000 \
>   -e SWML_BASIC_AUTH_USER=myuser \
>   -e SWML_BASIC_AUTH_PASSWORD=mypassword \
>   --name agent \
>   signalwire-agent
$
$ ## View logs
$ docker logs -f agent
$
$ ## Stop container
$ docker stop agent

Docker Compose

1 ## docker-compose.yml
2 version: '3.8'
3
4 services:
5   agent:
6     build: .
7     ports:
8       - "3000:3000"
9     environment:
10       - SWML_BASIC_AUTH_USER=${SWML_BASIC_AUTH_USER}
11       - SWML_BASIC_AUTH_PASSWORD=${SWML_BASIC_AUTH_PASSWORD}
12       - SWML_PROXY_URL_BASE=${SWML_PROXY_URL_BASE}
13     restart: unless-stopped
14     healthcheck:
15       test: ["CMD", "curl", "-f", "http://localhost:3000/health"]
16       interval: 30s
17       timeout: 10s
18       retries: 3
19
20   nginx:
21     image: nginx:alpine
22     ports:
23       - "443:443"
24       - "80:80"
25     volumes:
26       - ./nginx.conf:/etc/nginx/nginx.conf:ro
27       - ./certs:/etc/ssl/certs:ro
28     depends_on:
29       - agent
30     restart: unless-stopped

Run with:

$ docker-compose up -d

Kubernetes deployment

Kubernetes manifests are language-agnostic. The only difference is the Docker image referenced and any build steps. Use the appropriate Dockerfile from the section above to build your image, then deploy with the same manifests regardless of language.

Language	Image Build Command
Python	`docker build -f Dockerfile.python -t your-registry/agent:latest .`
TypeScript	`docker build -f Dockerfile.ts -t your-registry/agent:latest .`

Deployment manifest

1 ## deployment.yaml
2 apiVersion: apps/v1
3 kind: Deployment
4 metadata:
5   name: signalwire-agent
6   labels:
7     app: signalwire-agent
8 spec:
9   replicas: 3
10   selector:
11     matchLabels:
12       app: signalwire-agent
13   template:
14     metadata:
15       labels:
16         app: signalwire-agent
17     spec:
18       containers:
19       - name: agent
20         image: your-registry/signalwire-agent:latest
21         ports:
22         - containerPort: 3000
23         env:
24         - name: SWML_BASIC_AUTH_USER
25           valueFrom:
26             secretKeyRef:
27               name: agent-secrets
28               key: auth-user
29         - name: SWML_BASIC_AUTH_PASSWORD
30           valueFrom:
31             secretKeyRef:
32               name: agent-secrets
33               key: auth-password
34         resources:
35           requests:
36             memory: "256Mi"
37             cpu: "250m"
38           limits:
39             memory: "512Mi"
40             cpu: "500m"
41         livenessProbe:
42           httpGet:
43             path: /health
44             port: 3000
45           initialDelaySeconds: 10
46           periodSeconds: 30
47         readinessProbe:
48           httpGet:
49             path: /health
50             port: 3000
51           initialDelaySeconds: 5
52           periodSeconds: 10

Service manifest

1 ## service.yaml
2 apiVersion: v1
3 kind: Service
4 metadata:
5   name: signalwire-agent
6 spec:
7   selector:
8     app: signalwire-agent
9   ports:
10   - protocol: TCP
11     port: 80
12     targetPort: 3000
13   type: ClusterIP

Ingress manifest

1 ## ingress.yaml
2 apiVersion: networking.k8s.io/v1
3 kind: Ingress
4 metadata:
5   name: signalwire-agent
6   annotations:
7     nginx.ingress.kubernetes.io/ssl-redirect: "true"
8     cert-manager.io/cluster-issuer: "letsencrypt-prod"
9 spec:
10   ingressClassName: nginx
11   tls:
12   - hosts:
13     - agent.example.com
14     secretName: agent-tls
15   rules:
16   - host: agent.example.com
17     http:
18       paths:
19       - path: /
20         pathType: Prefix
21         backend:
22           service:
23             name: signalwire-agent
24             port:
25               number: 80

Secrets

1 ## secrets.yaml
2 apiVersion: v1
3 kind: Secret
4 metadata:
5   name: agent-secrets
6 type: Opaque
7 stringData:
8   auth-user: your-username
9   auth-password: your-secure-password

Kubernetes architecture

Deploying to Kubernetes

$ ## Create secrets
$ kubectl apply -f secrets.yaml
$
$ ## Deploy application
$ kubectl apply -f deployment.yaml
$ kubectl apply -f service.yaml
$ kubectl apply -f ingress.yaml
$
$ ## Check status
$ kubectl get pods -l app=signalwire-agent
$ kubectl get svc signalwire-agent
$ kubectl get ingress signalwire-agent
$
$ ## View logs
$ kubectl logs -f -l app=signalwire-agent
$
$ ## Scale deployment
$ kubectl scale deployment signalwire-agent --replicas=5

Horizontal Pod Autoscaler

1 ## hpa.yaml
2 apiVersion: autoscaling/v2
3 kind: HorizontalPodAutoscaler
4 metadata:
5   name: signalwire-agent
6 spec:
7   scaleTargetRef:
8     apiVersion: apps/v1
9     kind: Deployment
10     name: signalwire-agent
11   minReplicas: 2
12   maxReplicas: 10
13   metrics:
14   - type: Resource
15     resource:
16       name: cpu
17       target:
18         type: Utilization
19         averageUtilization: 70

Multi-architecture builds

1 ## Build for multiple architectures
2 FROM --platform=$TARGETPLATFORM python:3.11-slim
3
4 ## ... rest of Dockerfile

Build with:

$ docker buildx build --platform linux/amd64,linux/arm64 -t your-registry/agent:latest --push .

Container best practices

Security

Run as non-root user
Use minimal base images (slim, alpine)
Scan images for vulnerabilities
Don’t store secrets in images

Performance

Use multi-stage builds to reduce image size
Layer dependencies efficiently
Set appropriate resource limits

Reliability

Add health checks
Use restart policies
Configure proper logging
Set graceful shutdown handling
