Contexts and Workflows

The features in this chapter build on the fundamentals covered earlier. While basic agents handle free-form conversations well, many real-world applications require more structure: guided workflows that ensure certain information is collected, the ability to transfer between different “departments” or personas, recording for compliance, and integration with knowledge bases.

These advanced features transform simple voice agents into sophisticated conversational applications capable of handling complex business processes.

When to Use Contexts

Contexts are the SDK’s answer to a common challenge: how do you ensure a conversation follows a specific path? Regular prompts work well for open-ended conversations, but many business processes require structure — collecting specific information in a specific order, or routing callers through a defined workflow.

Think of contexts as conversation “states” or “modes.” Each context can have its own persona, available functions, and series of steps. The AI automatically manages transitions between contexts and steps based on criteria you define.

Use contexts when you need:

• Guaranteed step completion
• Controlled navigation
• Step-specific function access
• Context-dependent personas
• Department transfers
• Isolated conversation segments

Common context patterns:

• Data collection wizard: Gather customer information step-by-step (name, address, payment)
• Triage flow: Qualify callers before routing to appropriate department
• Multi-department support: Sales, Support, and Billing each with their own persona
• Appointment scheduling: Check availability, select time, confirm details
• Order processing: Select items, confirm order, process payment

Context Architecture

Understanding how contexts, steps, and navigation work together is essential for building effective workflows.

Key concepts:

• ContextBuilder: The top-level container that holds all your contexts
• Context: A distinct conversation mode (like “sales” or “support”), with its own persona and settings
• Step: A specific point within a context where certain tasks must be completed

The AI automatically tracks which context and step the conversation is in. When step criteria are met, it advances to the next allowed step. When context navigation is permitted and appropriate, it switches contexts entirely.

How state flows through contexts:

1. Caller starts in the first step of the default (or specified) context
2. AI follows the step’s instructions until step_criteria is satisfied
3. AI chooses from valid_steps to advance within the context
4. If valid_contexts allows, AI can switch to a different context entirely
5. When switching contexts, isolated, consolidate, or full_reset settings control what conversation history carries over

Basic Context Example

1
from signalwire import AgentBase
2
3
class OrderAgent(AgentBase):
4
    def __init__(self):
5
        super().__init__(name="order-agent")
6
        self.add_language("English", "en-US", "rime.spore")
7
8
        # Base prompt (required even with contexts)
9
        self.prompt_add_section(
10
            "Role",
11
            "You help customers place orders."
12
        )
13
14
        # Define contexts after setting base prompt
15
        contexts = self.define_contexts()
16
17
        # Add a context with steps
18
        order = contexts.add_context("default")
19
20
        order.add_step("get_item") \
21
            .set_text("Ask what item they want to order.") \
22
            .set_step_criteria("Customer has specified an item") \
23
            .set_valid_steps(["get_quantity"])
24
25
        order.add_step("get_quantity") \
26
            .set_text("Ask how many they want.") \
27
            .set_step_criteria("Customer has specified a quantity") \
28
            .set_valid_steps(["confirm"])
29
30
        order.add_step("confirm") \
31
            .set_text("Confirm the order details and thank them.") \
32
            .set_step_criteria("Order has been confirmed")
33
34
if __name__ == "__main__":
35
    agent = OrderAgent()
36
    agent.run()

Compact Step Definition

Steps can be fully configured in a single add_step() call using keyword arguments:

1
contexts = self.define_contexts()
2
order = contexts.add_context("default")
3
4
order.add_step("get_item",
5
    task="Ask what item they want to order.",
6
    bullets=["Show available items", "Confirm selection"],
7
    criteria="Customer has specified an item",
8
    functions=["check_inventory"],
9
    valid_steps=["get_quantity"]
10
)
11
12
order.add_step("get_quantity",
13
    task="Ask how many they want.",
14
    criteria="Customer has specified a quantity",
15
    valid_steps=["confirm"]
16
)
17
18
order.add_step("confirm",
19
    task="Confirm the order details and thank them.",
20
    criteria="Order has been confirmed"
21
)

The task parameter creates a POM section titled “Task” with the given text. The bullets, criteria, functions, and valid_steps parameters map to add_bullets(), set_step_criteria(), set_functions(), and set_valid_steps() respectively. You can still use the method-chaining API when you need more control.

Step Configuration

set_text()

Simple text prompt for the step:

add_section() / add_bullets()

POM-style structured prompts:

set_step_criteria()

Define when the step is complete:

set_valid_steps()

Control step navigation:

set_functions()

Restrict available functions per step:

set_valid_contexts()

Allow navigation to other contexts:

Step Behavior Flags

Control how steps transition without relying on criteria evaluation:

1
# End the conversation after this step (cannot combine with valid_steps)
2
step.set_end(True)
3
4
# Skip waiting for user input — proceed immediately
5
step.set_skip_user_turn(True)
6
7
# Auto-advance to the next step without evaluating criteria
8
step.set_skip_to_next_step(True)

These flags are useful for non-interactive steps like announcements, automated transitions, or terminal farewell steps.

Understanding Step Criteria

Step criteria tell the AI when a step is “complete” and it’s time to move on. Writing good criteria is crucial — too vague and the AI may advance prematurely; too strict and the conversation may get stuck.

Good criteria are:

• Specific and measurable
• Phrased as completion conditions
• Focused on what information has been collected

Examples of well-written criteria:

1
# Good: Specific, measurable
2
.set_step_criteria("Customer has provided their full name and email address")
3
4
# Good: Clear completion condition
5
.set_step_criteria("Customer has selected a product and confirmed the quantity")
6
7
# Good: Explicit confirmation
8
.set_step_criteria("Customer has verbally confirmed the order total")

Problematic criteria to avoid:

1
# Bad: Too vague
2
.set_step_criteria("Customer is ready")
3
4
# Bad: Subjective
5
.set_step_criteria("Customer seems satisfied")
6
7
# Bad: No clear completion point
8
.set_step_criteria("Help the customer")

Context Configuration

set_isolated()

Truncate conversation history when entering:

set_system_prompt()

New system prompt when entering context:

set_user_prompt()

Inject a user message when entering:

set_consolidate()

Summarize previous conversation when switching:

set_full_reset()

Completely reset conversation state:

add_enter_filler() / add_exit_filler()

Add transition phrases:

1
context.add_enter_filler("en-US", [
2
    "Let me connect you with our support team...",
3
    "Transferring you to a specialist..."
4
])
5
6
context.add_exit_filler("en-US", [
7
    "Returning you to the main menu...",
8
    "Back to the sales department..."
9
])

Multi-Context Example

1
from signalwire import AgentBase
2
3
class MultiDepartmentAgent(AgentBase):
4
    def __init__(self):
5
        super().__init__(name="multi-dept-agent")
6
        self.add_language("English-Sales", "en-US", "rime.spore")
7
        self.add_language("English-Support", "en-US", "rime.cove")
8
        self.add_language("English-Manager", "en-US", "rime.marsh")
9
10
        self.prompt_add_section(
11
            "Instructions",
12
            "Guide customers through sales or transfer to appropriate departments."
13
        )
14
15
        contexts = self.define_contexts()
16
17
        # Sales context
18
        sales = contexts.add_context("sales") \
19
            .set_isolated(True) \
20
            .add_section("Role", "You are Alex, a sales representative.")
21
22
        sales.add_step("qualify") \
23
            .add_section("Task", "Determine customer needs") \
24
            .set_step_criteria("Customer needs are understood") \
25
            .set_valid_steps(["recommend"]) \
26
            .set_valid_contexts(["support", "manager"])
27
28
        sales.add_step("recommend") \
29
            .add_section("Task", "Make product recommendations") \
30
            .set_step_criteria("Recommendation provided") \
31
            .set_valid_contexts(["support", "manager"])
32
33
        # Support context
34
        support = contexts.add_context("support") \
35
            .set_isolated(True) \
36
            .add_section("Role", "You are Sam, technical support.") \
37
            .add_enter_filler("en-US", [
38
                "Connecting you with technical support...",
39
                "Let me transfer you to our tech team..."
40
            ])
41
42
        support.add_step("assist") \
43
            .add_section("Task", "Help with technical questions") \
44
            .set_step_criteria("Technical issue resolved") \
45
            .set_valid_contexts(["sales", "manager"])
46
47
        # Manager context
48
        manager = contexts.add_context("manager") \
49
            .set_isolated(True) \
50
            .add_section("Role", "You are Morgan, the store manager.") \
51
            .add_enter_filler("en-US", [
52
                "Let me get the manager for you...",
53
                "One moment, connecting you with management..."
54
            ])
55
56
        manager.add_step("escalate") \
57
            .add_section("Task", "Handle escalated issues") \
58
            .set_step_criteria("Issue resolved by manager") \
59
            .set_valid_contexts(["sales", "support"])
60
61
if __name__ == "__main__":
62
    agent = MultiDepartmentAgent()
63
    agent.run()

Navigation Flow

Within Context (Steps)

• set_valid_steps(["next"]) - Go to next sequential step
• set_valid_steps(["step_name"]) - Go to specific step
• set_valid_steps(["a", "b"]) - Multiple options

Context-Level Valid Steps

You can set valid_steps at the context level to apply default step navigation for all steps in the context. Step-level valid_steps overrides context-level when set.

1
contexts = self.define_contexts()
2
order = contexts.add_context("default")
3
4
# All steps in this context can navigate to "cancel" by default
5
order.set_valid_steps(["next", "cancel"])
6
7
order.add_step("get_item",
8
    task="Ask what item they want to order.",
9
    criteria="Customer has specified an item"
10
)
11
order.add_step("get_quantity",
12
    task="Ask how many they want.",
13
    criteria="Customer has specified a quantity"
14
)
15
order.add_step("cancel",
16
    task="Cancel the order and apologize."
17
)

Between Contexts

• set_valid_contexts(["other_context"]) - Allow context switch
• AI calls change_context("context_name") automatically
• Enter/exit fillers provide smooth transitions

Context Entry Behavior

• isolated=True - Clear conversation history
• consolidate=True - Summarize previous conversation
• full_reset=True - Complete prompt replacement

Context Manipulation

After defining contexts and steps, you can retrieve, modify, reorder, or remove them programmatically.

Retrieving Contexts and Steps

1
contexts = self.define_contexts()
2
3
# Build your contexts...
4
order = contexts.add_context("default")
5
order.add_step("greeting", task="Greet the caller.")
6
7
# Later, retrieve and modify
8
ctx = contexts.get_context("default")
9
step = ctx.get_step("greeting")
10
step.clear_sections()
11
step.set_text("Welcome! How can I help you today?")

Removing and Reordering Steps

1
# Remove a step entirely
2
ctx.remove_step("obsolete_step")
3
4
# Move a step to a new position (0-indexed)
5
ctx.move_step("confirm", 0)  # Move "confirm" to the first position

Clearing Step Content

Use clear_sections() to remove all POM sections and text from a step so you can repopulate it:

1
step = ctx.get_step("collect_info")
2
step.clear_sections()
3
step.add_section("Task", "Updated instructions for collecting info.")

Gather Info Steps

The gather info system lets you define structured question sequences within a step. Questions are presented one at a time via the SignalWire platform’s built-in gather mechanism, producing zero tool_call/tool_result entries in the LLM conversation history. This keeps the history clean and focused.

Basic Gather Info

1
from signalwire import AgentBase
2
3
class IntakeAgent(AgentBase):
4
    def __init__(self):
5
        super().__init__(name="intake-agent")
6
        self.add_language("English", "en-US", "rime.spore")
7
8
        self.prompt_add_section(
9
            "Role",
10
            "You collect patient intake information."
11
        )
12
13
        contexts = self.define_contexts()
14
        ctx = contexts.add_context("default")
15
16
        intake = ctx.add_step("intake")
17
        intake.set_gather_info(
18
            output_key="patient_info",
19
            completion_action="next_step",
20
            prompt="You are collecting patient information. Be friendly and professional."
21
        )
22
        intake.add_gather_question(
23
            key="full_name",
24
            question="What is your full name?",
25
            type="string",
26
            confirm=True
27
        )
28
        intake.add_gather_question(
29
            key="dob",
30
            question="What is your date of birth?",
31
            type="string"
32
        )
33
        intake.add_gather_question(
34
            key="reason",
35
            question="What is the reason for your visit today?",
36
            type="string",
37
            prompt="Be empathetic when asking about the reason for the visit."
38
        )
39
        intake.set_valid_steps(["summary"])
40
41
        ctx.add_step("summary",
42
            task="Summarize the collected information and confirm with the patient.",
43
            criteria="Patient has confirmed the information is correct"
44
        )
45
46
if __name__ == "__main__":
47
    agent = IntakeAgent()
48
    agent.run()

Gather Info Parameters

Gather Question Parameters

When to Use Gather Info vs Regular Steps

Validation Rules

The ContextBuilder validates your configuration:

• Single context must be named “default”
• Every context must have at least one step
• valid_steps must reference existing steps (or “next”)
• valid_contexts must reference existing contexts
• Cannot mix set_text() with add_section() on same step
• Cannot mix set_prompt() with add_section() on same context

Step and Context Methods Summary

Context Switching Behavior

When the AI switches between contexts, several things can happen depending on your configuration. Understanding these options helps you create smooth transitions.

Isolated Contexts

When isolated=True, the conversation history is cleared when entering the context. This is useful when:

• You want a clean slate for a new department
• Previous context shouldn’t influence the new persona
• You’re implementing strict separation between workflow segments

1
support = contexts.add_context("support") \
2
    .set_isolated(True)  # Fresh start when entering support

The caller won’t notice — the AI simply starts fresh with no memory of the previous context.

Consolidated Contexts

When consolidate=True, the AI summarizes the previous conversation before switching. This preserves important information without carrying over the full history:

1
billing = contexts.add_context("billing") \
2
    .set_consolidate(True)  # Summarize previous conversation

The summary includes key facts and decisions, giving the new context awareness of what happened without the full transcript.

Full Reset Contexts

full_reset=True goes further than isolation — it completely replaces the system prompt and clears all state:

1
escalation = contexts.add_context("escalation") \
2
    .set_full_reset(True)  # Complete prompt replacement

Use this when the new context needs to behave as if it were a completely different agent.

Combining with Enter/Exit Fillers

Fillers provide audio feedback during context switches, making transitions feel natural:

1
support = contexts.add_context("support") \
2
    .set_isolated(True) \
3
    .add_enter_filler("en-US", [
4
        "Let me transfer you to technical support.",
5
        "One moment while I connect you with a specialist."
6
    ]) \
7
    .add_exit_filler("en-US", [
8
        "Returning you to the main menu.",
9
        "Transferring you back."
10
    ])

The AI randomly selects from the filler options, providing variety in the transitions.

Debugging Context Flows

When contexts don’t behave as expected, use these debugging strategies:

1. Check step criteria: If stuck on a step, the criteria may be too strict. Temporarily loosen them to verify the flow works.

2. Verify navigation paths: Ensure valid_steps and valid_contexts form a complete graph. Every step should have somewhere to go (unless it’s a terminal step).

3. Test with swaig-test: The testing tool shows context configuration in the SWML output:

$
swaig-test your_agent.py --dump-swml | grep -A 50 "contexts"

4. Add logging in handlers: If you have SWAIG functions, log when they’re called to trace the conversation flow.

5. Watch for validation errors: The ContextBuilder validates your configuration at runtime. Check logs for validation failures.

Best Practices

DO:

• Set clear step_criteria for each step
• Use isolated=True for persona changes
• Add enter_fillers for smooth transitions
• Define valid_contexts to enable department transfers
• Test navigation paths thoroughly
• Provide escape routes from every step (avoid dead ends)
• Use consolidate=True when context needs awareness of previous conversation

DON’T:

• Create circular navigation without exit paths
• Skip setting a base prompt before define_contexts()
• Mix set_text() with add_section() on the same step
• Forget to validate step/context references
• Use full_reset unless you truly need a complete persona change
• Make criteria too vague or too strict
