The Complete Call Flow

Understanding the request lifecycle helps you debug issues and optimize your agents. Here’s the complete flow:

Complete call lifecycle. — Complete Call Lifecycle

Phase 1: Call Setup

When a call arrives at SignalWire:

Key points:

SignalWire knows which agent to contact based on phone number configuration
The request includes Basic Auth credentials
POST is the default; GET requests are also supported for SWML retrieval

Phase 2: SWML Generation

Your agent builds and returns the SWML document:

1 ## Inside AgentBase._render_swml()
2
3 def _render_swml(self, request_body=None):
4     """Generate SWML document for this agent."""
5
6     # 1. Build the prompt (POM or text)
7     prompt = self._build_prompt()
8
9     # 2. Collect all SWAIG functions
10     functions = self._tool_registry.get_functions()
11
12     # 3. Generate webhook URLs with security tokens
13     webhook_url = self._build_webhook_url("/swaig")
14
15     # 4. Assemble AI configuration
16     ai_config = {
17         "prompt": prompt,
18         "post_prompt": self._post_prompt,
19         "post_prompt_url": self._build_webhook_url("/post_prompt"),
20         "SWAIG": {
21             "defaults": {"web_hook_url": webhook_url},
22             "functions": functions
23         },
24         "hints": self._hints,
25         "languages": self._languages,
26         "params": self._params
27     }
28
29     # 5. Build complete SWML document
30     swml = {
31         "version": "1.0.0",
32         "sections": {
33             "main": [
34                 {"answer": {}},
35                 {"ai": ai_config}
36             ]
37         }
38     }
39
40     return swml

Phase 3: AI Conversation

Once SignalWire has the SWML, it executes the instructions:

AI conversation loop. — AI Conversation Loop

AI Parameters that control this loop:

Parameter	Default	Purpose
`end_of_speech_timeout`	500ms	Wait time after user stops speaking
`attention_timeout`	15000ms	Max silence before AI prompts
`inactivity_timeout`	30000ms	Max silence before ending call
`barge_match_string`	-	Words that immediately interrupt AI

Phase 4: Function Calls

When the AI needs to call a function:

SWAIG function call phase. — SWAIG Function Call

Phase 5: Call End

When the call ends, the post-prompt summary is sent:

Handling Post-Prompt

Configure post-prompt handling in your agent:

Language	Set Post-Prompt
Python	`agent.set_post_prompt("Summarize this call...")`
TypeScript	`agent.setPostPrompt('Summarize this call...')`

Python

TypeScript

1 from signalwire import AgentBase
2
3 class MyAgent(AgentBase):
4     def __init__(self):
5         super().__init__(name="my-agent")
6
7         self.set_post_prompt(
8             "Summarize this call including: "
9             "1) The caller's main question or issue "
10             "2) How it was resolved "
11             "3) Any follow-up actions needed"
12         )
13
14     def on_post_prompt(self, data):
15         """Handle the call summary."""
16         summary = data.get("post_prompt_data", {})
17         call_id = data.get("call_id")
18         self.log_call_summary(call_id, summary)

Request/Response Headers

SWML Request (GET or POST /)

1 GET / HTTP/1.1
2 Host: your-agent.com
3 Authorization: Basic c2lnbmFsd2lyZTpwYXNzd29yZA==
4 Accept: application/json
5 X-Forwarded-For: signalwire-ip
6 X-Forwarded-Proto: https

SWML Response

1 HTTP/1.1 200 OK
2 Content-Type: application/json
3
4 {"version": "1.0.0", "sections": {...}}

SWAIG Request (POST /swaig)

1 POST /swaig HTTP/1.1
2 Host: your-agent.com
3 Authorization: Basic c2lnbmFsd2lyZTpwYXNzd29yZA==
4 Content-Type: application/json
5
6 {"action": "swaig_action", "function": "...", ...}

SWAIG Response

1 HTTP/1.1 200 OK
2 Content-Type: application/json
3
4 {"response": "...", "action": [...]}

Debugging the Lifecycle

View SWML Output

$ ## See what your agent returns
$ curl -u signalwire:password http://localhost:3000/ | jq '.'
$
$ ## Using swaig-test
$ swaig-test my_agent.py --dump-swml

Test Function Calls

$ ## Call a function directly
$ swaig-test my_agent.py --exec get_balance --account_id 12345
$
$ ## With verbose output
$ swaig-test my_agent.py --exec get_balance --account_id 12345 --verbose

Monitor Live Traffic

1 from signalwire import AgentBase
2
3 class DebugAgent(AgentBase):
4     def __init__(self):
5         super().__init__(name="debug-agent")
6
7     def on_swml_request(self, request_data=None, callback_path=None, request=None):
8         """Called when SWML is requested."""
9         if request:
10             print(f"SWML requested from: {request.client.host}")
11             print(f"Headers: {dict(request.headers)}")
12
13     def on_swaig_request(self, function_name, args, raw_data):
14         """Called before each SWAIG function."""
15         print(f"Function called: {function_name}")
16         print(f"Arguments: {args}")
17         print(f"Call ID: {raw_data.get('call_id')}")

Error Handling

SWML Errors

If your agent can’t generate SWML:

1 def _render_swml(self):
2     try:
3         return self._build_swml()
4     except Exception as e:
5         # Return minimal valid SWML
6         return {
7             "version": "1.0.0",
8             "sections": {
9                 "main": [
10                     {"answer": {}},
11                     {"play": {"url": "https://example.com/error.mp3"}},
12                     {"hangup": {}}
13                 ]
14             }
15         }

SWAIG Errors

If a function fails:

1 def get_balance(self, args, raw_data):
2     try:
3         balance = self.lookup_balance(args.get("account_id"))
4         return FunctionResult(f"Your balance is ${balance}")
5     except DatabaseError:
6         return FunctionResult(
7             "I'm having trouble accessing account information right now. "
8             "Please try again in a moment."
9         )
10     except Exception as e:
11         # Log the error but return user-friendly message
12         self.logger.error(f"Function error: {e}")
13         return FunctionResult(
14             "I encountered an unexpected error. "
15             "Let me transfer you to a representative."
16         )

Next Steps

Now that you understand the complete lifecycle, let’s look at how security works throughout this flow.
