Architecture

What You’ll Learn

This chapter covers the foundational concepts you need to build effective voice AI agents:

1. Architecture - How AgentBase and its mixins work together
2. SWML - The markup language that controls call flows
3. SWAIG - The gateway that lets AI call your functions
4. Lifecycle - How requests flow through the system
5. Security - Authentication and token-based function security

Prerequisites

Before diving into these concepts, you should have:

• Completed the Getting Started chapter
• A working agent running locally
• Basic understanding of HTTP request/response patterns

The Big Picture

Key Terminology

Chapter Contents

Why These Concepts Matter

Understanding these core concepts helps you:

• Debug effectively - Know where to look when things go wrong
• Build efficiently - Use the right tool for each task
• Scale confidently - Understand how the system handles load
• Extend properly - Add custom functionality the right way

The Mixin Composition Pattern

AgentBase doesn’t inherit from a single monolithic class. Instead, it combines nine specialized mixins plus the SWMLService base class:

Each Mixin’s Role

AuthMixin - Authentication & Security

Handles basic HTTP authentication for webhook endpoints.

Key methods:

• Validates incoming requests against stored credentials
• Generates credentials if not provided via environment
• Protects SWAIG function endpoints

WebMixin - HTTP Server & Routing

Manages the FastAPI application and HTTP endpoints.

1
# Automatically registers these routes:
2
# GET  /          -> Returns SWML document
3
# POST /          -> Returns SWML document
4
# POST /swaig     -> Handles SWAIG function calls
5
# POST /post_prompt -> Receives call summaries
6
# GET  /debug     -> Debug information (dev only)

Key features:

• Runs uvicorn server via agent.run()
• Handles proxy detection (ngrok, load balancers)
• Manages request/response lifecycle

SWMLService - SWML Document Generation

The foundation for building SWML documents.

1
# SWMLService provides:
2
# - Schema validation against SWML spec
3
# - Verb handler registry
4
# - Document rendering pipeline

Key responsibilities:

• Validates SWML structure against JSON schema
• Registers verb handlers (answer, ai, connect, etc.)
• Renders final SWML JSON

PromptMixin - Prompt Management

Manages AI system prompts using POM (Prompt Object Model).

Key features:

• Structured prompt building with sections
• Support for bullets, subsections
• Post-prompt for call summaries

ToolMixin - SWAIG Function Management

Handles registration and execution of SWAIG functions.

Key features:

• Multiple registration methods (define_tool, decorators, DataMap)
• Parameter validation
• Security token generation

SkillMixin - Skill Plugin Management

Loads and manages reusable skill plugins.

Key features:

• Auto-discovery of skill modules
• Dependency checking
• Configuration validation

AIConfigMixin - AI Behavior Configuration

Configures the AI’s voice, language, and behavior parameters.

Key features:

• Voice and language settings
• Speech recognition hints
• AI behavior parameters

ServerlessMixin - Deployment Adapters

Provides handlers for serverless deployments.

1
# AWS Lambda
2
handler = agent.serverless_handler
3
4
# Google Cloud Functions
5
def my_function(request):
6
    return agent.cloud_function_handler(request)
7
8
# Azure Functions
9
def main(req):
10
    return agent.azure_function_handler(req)

Key features:

• Environment auto-detection
• Request/response adaptation
• URL generation for each platform

StateMixin - State Management

Manages session and call state.

1
# State is passed via global_data in SWML
2
# and preserved across function calls

Key features:

• Session tracking
• State persistence patterns
• Call context management

MCPServerMixin - MCP Protocol Support

Exposes agent tools as an MCP (Model Context Protocol) server endpoint.

Key features:

• MCP JSON-RPC 2.0 protocol support
• Automatic tool exposure at /mcp endpoint
• Converts SWAIG functions to MCP tool format

Key Internal Components

Beyond the mixins, AgentBase uses several internal managers:

ToolRegistry

• Stores SWAIG functions
• Handles function lookup
• Generates webhook URLs

PromptManager

• Manages prompt sections
• Builds POM structure
• Handles post-prompts

SessionManager

• Token generation
• Token validation
• Security enforcement

SkillManager

• Skill discovery
• Skill loading
• Configuration validation

SchemaUtils

• SWML schema loading
• Document validation
• Schema-driven help

VerbHandlerRegistry

• Verb registration
• Handler dispatch
• Custom verb support

Creating Your Own Agent

When you create an agent, you get all functionality automatically:

1
from signalwire import AgentBase, FunctionResult
2
3
class CustomerServiceAgent(AgentBase):
4
    def __init__(self):
5
        super().__init__(name="customer-service")
6
        self.add_language("English", "en-US", "rime.spore")
7
        self.set_params({"end_of_speech_timeout": 500})
8
        self.prompt_add_section("Role", "You are a helpful agent.")
9
        self.define_tool(
10
            name="lookup_order",
11
            description="Look up an order by ID",
12
            parameters={"order_id": {"type": "string", "description": "Order ID"}},
13
            handler=self.lookup_order
14
        )
15
        self.add_skill("datetime")
16
17
    def lookup_order(self, args, raw_data):
18
        order_id = args.get("order_id")
19
        return FunctionResult(f"Order {order_id}: Shipped, arrives tomorrow")
20
21
if __name__ == "__main__":
22
    agent = CustomerServiceAgent()
23
    agent.run()

Benefits of This Architecture

Next Steps

Now that you understand how AgentBase is structured, let’s look at the SWML documents it generates.
