Mapping Numbers

Mapping Numbers

Connect phone numbers to your agent using SignalWire’s SWML Script resources.

Overview

SignalWire uses SWML Script resources to connect phone numbers to your agent. When a call comes in, SignalWire fetches SWML from your agent’s URL and executes it.

Step 1: Create a SWML Script Resource

1. Log in to SignalWire dashboard
2. Navigate to My Resources in the left sidebar
3. Click Script
4. Click New SWML Script
5. Fill in the fields:
   • Name: Give your script a name (e.g., “my-agent”)
   • Handle Calls Using: Select External URL
   • Primary Script URL: Enter your agent URL with credentials
     • Format: https://user:pass@your-domain.com/agent
6. Click Create

Step 2: Add a Phone Number or Address

After creating the script, you’ll see the resource configuration page:

1. Click the Addresses & Phone Numbers tab
2. Click + Add
3. Choose your address type:
   • Phone Number: For receiving calls from regular phones (PSTN)
   • SIP Address: For receiving SIP calls
   • Alias: For referencing this resource by a custom name
4. Follow the prompts to select or purchase a phone number
5. Your number is now connected to your agent!

Step 3: Test Your Setup

1. Ensure your agent is running locally
2. Ensure ngrok is running (if using tunneling)
3. Call your SignalWire phone number
4. Hear your agent respond!

URL Format

Your agent URL structure depends on your setup:

Single Agent:

https://your-server.com/

Multiple Agents:

https://your-server.com/support
https://your-server.com/sales
https://your-server.com/billing

With Authentication (recommended):

https://user:pass@your-server.com/

Using ngrok for Development

$
# Start your agent locally
$
python my_agent.py
$
$
# In another terminal, start ngrok
$
ngrok http 3000
$
$
# Use the ngrok HTTPS URL in SignalWire
$
# https://abc123.ngrok.io

For a static URL that doesn’t change on restart:

$
ngrok http --url=https://your-name.ngrok-free.app 3000

Basic Authentication

The SDK automatically generates authentication credentials on startup:

Agent 'my-agent' is available at:
URL: http://localhost:3000
Basic Auth: signalwire:7vVZ8iMTOWL0Y7-BG6xaN3qhjmcm4Sf59nORNdlF9bs (source: generated)

For persistent credentials, set environment variables:

$
export SWML_BASIC_AUTH_USER=signalwire
$
export SWML_BASIC_AUTH_PASSWORD=your-secure-password

In SignalWire, use URL with credentials:

https://signalwire:your-secure-password@your-server.com/

Multi-Agent Server

Run multiple agents on one server:

1
from signalwire_agents import AgentServer
2
3
server = AgentServer()
4
5
# Register agents at different paths
6
server.register(SupportAgent(), "/support")
7
server.register(SalesAgent(), "/sales")
8
server.register(BillingAgent(), "/billing")
9
10
server.run(host="0.0.0.0", port=3000)

Create a separate SWML Script resource for each agent:

Fallback URL

Configure a fallback for errors:

Fallback triggers on:

• Connection timeout
• HTTP 5xx errors
• Invalid SWML response

Troubleshooting

Common Issues

Test Checklist

$
# 1. Agent running?
$
curl http://localhost:3000/
$
$
# 2. Tunnel working?
$
curl https://your-name.ngrok-free.app/
$
$
# 3. Auth working?
$
curl https://user:pass@your-name.ngrok-free.app/
$
$
# 4. SWML valid?
$
swaig-test agent.py --dump-swml

Verification Checklist

Before going live:

• Agent is deployed and running
• HTTPS URL is accessible
• URL returns valid SWML on POST request
• Basic auth is configured
• SWML Script resource created in SignalWire
• Phone number added to SWML Script resource
• Test call completes successfully
